High-Definition Imaging – HD cameras with high-speed processing for precise identification.
User-Friendly Operation – Simple interface with one-key automation for easy use.
Multi-Purpose Application – Suitable for walnuts, cashews, plastics, garlic, chili, herbs, and more.
Multi-Dimensional Sorting – Combines color, shape, and size sorting to remove micro color differences and tiny defects.
High Stability & Efficiency – Stable performance with high accuracy, low carryover, and low energy consumption.
Dual-Camera Design (Double-Deck Models) – Upper and lower cameras on each deck for more accurate sorting.
Precision Ejectors – Stable rejection with low air consumption, ideal for small materials (2–6 cm).
Remote Support – Online live video guidance for installation, startup, and commissioning worldwide.
| Model | BL-30 | BL-60 | BL-120 |
| Executing Unit | 64 | 128 | 256 |
| Throughout(t/h) | 0.5~1.0 | 1~3 | 2~4 |
| Voltage(V) | 110/220V-50/60Hz | 110/220V-50/60Hz | 110/220V-50/60Hz |
| Air Pressure(MPa) | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 |
| Power(kW) | 2.0 | 2.5 | 4.8 |
| Weight(kg) | 800 | 1000 | 1500 |
| Dimension(L*W*H/mm) | 2040*800*1630 | 2040*1120*1630 | 2040*1440*1630 |
Note:Subject to different impurities of raw materials,parameters listed in above table will change to some extent.
